Profile grinder and dressing tool specifications:
Center height: 80 mm
Indexing possibilities: 24
Indexing scale: 360° rotatable
Concentricity: 0.005 mm
Horizontal deviation: 0.005 mm
Vertical deviation: 0.005 mm
Specification of the prism receiver:
Max. clamping diameter:32 mm
Stroke of the prism receiver in Y-axis:25 mm
Stroke of the prism receiver in X-axis:2 x 12.5 mm = 25 mm
